Ubiquiti WAVE-MLO5 WiFi7 5GHz max. 5Gbps outdoor
Kód: WAVE-MLO5
Podrobný popis
Vysoce výkonná duální 5 GHz WiFi 7 komunikační vysílač s technologií pro Multi-Link operation (MLO) technologii pro zvýšenou propustnost a spolehlivou konektivitu.
|
Mechanical |
|
|
Dimensions |
249.3 x 82 x 47.6 mm (9.8 x 3.2 x 1.9") |
|
Weight |
575 g (1.3 lb) |
|
Enclosure material |
Aluminum alloy, UV-resistant polycarbonate |
|
Mount material |
Strap: stainless metal |
|
Pole mount diameter |
25.4 to 50.8 mm (1 to 2") on pipe outer diameter |
|
Weatherproofing |
IPX6 |
|
Hardware |
|
|
Processor |
Quad-core IPQ5322 at 1.5 GHz |
|
Memory |
DDR4 1 GB |
|
Networking interface |
(1) 10 GbE RJ45 port |
|
RF connectors |
(2) RP-SMA (Waterproof) |
|
Max. power consumption |
20W |
|
Power method |
Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) |
|
Power supply |
54V DC, 0.56A, 10 GbE PoE adapter (Included) |
|
Supported voltage range |
44–54V DC 22–27V DC |
|
Max. TX power* |
|
|
MIMO |
|
|
GPS |
Yes |
|
Button |
(1) Factory reset |
|
LEDs |
(1) Power, (1) Ethernet, (1) GPS, (4) signal |
|
Ambient operating temperature |
-40 to 60° C (-40 to 140° F) |
|
Ambient operating humidity |
5 to 95% noncondensing |
|
Certifications |
FCC, IC, CE |
|
Software |
|
|
Operating mode |
PtP |
|
Services |
UISP, ping watchdog, NTP client |
|
Tools |
Alignment, speed test, ping, traceroute, discovery, site survey |
|
Network |
Bridge mode |
|
Total throughput |
5+ Gbps |
|
Max. range* |
100 km |
|
Encryption |
WPA3-PSK (AES) |
|
RF |
|
|
Operating frequency* |
5180 – 5320, 5500 – 5700, 5745 – 5825 MHz *Depends on regulatory region. |
|
Channel bandwidth |
Radio 1: 20, 40, 80, 160 MHz |
|
Modulation |
BPSK (½), QPSK (½), QPSK (¾), 16QAM (½), 16QAM (¾), 64QAM (?), 64QAM (¾), 64QAM (?), 256QAM (¾), 256QAM (?), 1024QAM (¾), 1024QAM (?), 4096QAM (¾), 4096QAM (?) |
Dodatočné parametre
| Kategória: | Access pointy / Bridge |
|---|---|
| Záruka: | 2 roky |
| Hmotnosť: | 0.73 kg |
| EAN: | 810084699218 |
