Zyxel GS1915-24E, 24-port GbE Smart hybrid mode Switch, standalone or NebulaFlex Cloud, rackmount, fanless

Zyxel GS1915-24E, 24-port GbE Smart hybrid mode Switch, standalone or NebulaFlex Cloud, rackmount, fanless Item Features Standard Compliance IEEE 802.3 10BASE-T Ethernet* IEEE 802.3u 100BASE-TX Ethernet* IEEE 802.3ab 1000BASE-T Ethernet* IEEE 802.3x flow control IEEE 802.3af PoE* IEEE 802.3at PoE+* IEEE 802.3az EEE support/Green Ethernet IEEE 802.1p CoS support* * Cloud and standalone modes supported features Resilience and Availability IEEE 802.1D Spanning Tree Protocol (STP)* IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)* IEEE 802.3ad LACP* (max # trunks/links per trunk): 8/8EP: 4 groups/8 links per group 24E/24EP: 8 groups/8 links per group Loop guard* Dual configuration files Dual images* * Cloud and standalone modes supported features Traffic Control 802.1Q Static VLANs: 256* Port-based VLAN Voice VLAN* MAC-based VLAN Vendor ID based VLAN* VLAN Trunking* LACP algorithm of source/destination IP * Cloud and standalone modes supported features Security Layer 2 MAC filtering Static MAC forwarding SSH v2 SSL Port isolation* Port security MAC freeze CPU protection SHA2 HTTPS Certification Login authentication by RADIUS RADIUS accounting Authorization on RADIUS Multiple RADIUS servers DHCP Snooping * Cloud and standalone modes supported features Quality of Service (QoS) 802.1p queuing methods: SPQ, WRR, WFQ Storm control: broadcast, multicast, unknown unicast (DLF)* Port-based rate limiting (ingress/ egress)* 802.3x flow control 802.1p Class of Service (SPQ, WFQ, SPQ/WFQ combination capable) DiffServ (DSCP) * Cloud and standalone modes supported features Layer 2 Multicast L2 Multicast* Static L2 Multicast Forwarding IGMP snooping (v1, v2, v3)* * Cloud and standalone modes supported features Manageability SNMP v1*, v2c*, v3 SNMP trap group RMON (1, 2, 3, 9) ICMP echo/echo reply Syslog* Display port utilization* IEEE 802.1AB LLDP IEEE 802.1AB LLDP-MED Custom default Support NebulaFlex for Cloud Management * Cloud and standalone modes supported features IPv6 Management IPv6 over Ethernet (RFC 2464) IPv6 addressing architecture (RFC 4291) Dual stack (RFC4213) ICMPv6 (RFC4884) Path MTU (RFC 1981) Minimum Path MTU size of 1280 (RFC 5905) Encapsulation for maximum PMTU size of 1500 Neighbor Discovery (RFC4861) Device Management Standalone management by Web interface Cloud management by Nebula Control Center* Setup Wizard Management through Web, SNMP Remote firmware upgrade by FTP/Web Configuration saving and retrieving DHCP client* DHCP relay per VLAN Daylight saving* NTP (IPv4/IPv6) Port mirroring* Schedule PoE* PoE default consumption mode* * Cloud and standalone modes supported features MIB Zyxel private common MIB RFC 1066 TCP/IP-based MIB RFC 1213, 1157 SNMPv2c/v3 MIB RFC 1493 bridge MIB RFC 1643 Ethernet MIB RFC 1757 RMON group 1, 2, 3, 9 RFC 2011, 2012, 2013 SNMPv2 MIB RFC 2233 SMIv2 MIB RFC 2358 Ethernet-like MIB RFC 2674 bridge MIB extension RFC 2819, 2925 Remote Management MIB RFC 3621 Power Ethernet MIB RFC 4293 Management Information Base (MIB) for IP RFC 4292 IP forwarding table MIB RFC 4022 management information base for transmission control protocol RFC 4113 management information base for user datagram protocol Zyxel One Network ZON Utility* Discovery of Zyxel switches, APs and gateways Centralized and batch configurations: IP configuration IP renew Device factory reset Device reboot Device locating Web GUI access Password configuration One-click quick association with Zyxel AP Configurator (ZAC) Automatic detection of the latest firmware Displays device serial number and hardware version Cloud mode on/off option for Hybrid series devices * Cloud and standalone modes supported features Smart Connect Discover neighboring devices One-click remote management access to the neighboring Zyxel devices Reset neighboring devices remotely to factory defaults Power cycle neighboring powered devices (PoE switches only) Certifications EMC CE, FCC, RCM, Class A BSMI CNS 13438 Safety LVD EN 62368-1 BSMI CNS 14336-1 RoHS
