| Part No | 90NB15L1-M009T0 |
| Sales Model Name | H7606WM-OLED121X |
| EAN Code | 4711636442121 |
| UPC Code | 199291442122 |
| WEEE | 1.681 |
| BASE UNIT | VSNB15L1-BU4100 |
| |
| Marketing Name | ProArt P16 |
| Operating System | Windows 11 Pro |
| LCD cover-material | Aluminum |
| LCD cover-color | Nano Black |
| Top case-material | Aluminum |
| Top case-color | Nano Black |
| Keyboard color | Black |
| Bottom case-material | Aluminum |
| Bottom case-color | Nano Black |
| Military grade | US MIL-STD 810H military-grade standard |
| Touch Panel | Touch screen |
| Panel Size | 16.0-inch |
| Resolution | 3K (2880 x 1800) OLED 16:10 aspect ratio |
| Response time | 0.2ms response time |
| Refresh rate | 120Hz refresh rate |
| Brightness | 500nits |
| Peak Brightness | 1000nits HDR peak brightness |
| Color gamut | 100% DCI-P3 color gamut |
| Gamut mapping | Yes |
| Contrast ratio | 1,000,000:1 |
| VESA CERTIFIED Display HDR | VESA CERTIFIED Display HDR True Black 500 |
| Color depth | 1.07 billion colors |
| Pantone | PANTONE Validated |
| Surface texture of display | Glossy display |
| Low blue light | 70% less harmful blue light |
| TÜV Rheinland-certified | TÜV Rheinland-certified |
| SGS Eye Care Display | SGS Eye Care Display |
| Screen-to-body ratio | 88% |
| Stylus support | With stylus support |
| Processor | AMD Ryzen™ AI 9 HX 370 Processor 2.0GHz (36MB Cache, up to 5.1GHz, 12 cores, 24 Threads); AMD XDNA™ NPU up to 50TOPS |
| Chipset | N/A |
| Discrete/Share | Discrete |
| Intergrated GPU | AMD Radeon™ Graphics |
| Graphics | NVIDIA® GeForce RTX™ 5060 Laptop GPU |
| Graphic Memory | 8GB GDDR7 |
| Neural Processor | AMD XDNA™ NPU up to 50TOPS |
| Expansion Slot(includes used) | 1x M.2 2280 PCIe 4.0x4 + 1x M.2 2280 PCIe 4.0x2 |
| On board memory | 32GB LPDDR5X on board |
| Total System Memory | LPDDR5X 32GB |
| Storage | 2TB M.2 NVMe™ PCIe® 4.0 SSD |
| Front-facing camera | FHD camera with IR function to support Windows Hello |
| Wireless | Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card (*Bluetooth® version may change with OS version different.) |
| Keyboard type | Backlit Chiclet Keyboard |
"| Touchpad | Seamless touchpad
support DialPad |
"
| FingerPrint | N/A |
"| I/O ports | 1x USB 3.2 Gen 2 Type-C with support for display / power delivery (data speed up to 10Gbps)
1x USB 4.0 Gen 3 Type-C with support for display / power delivery (data speed up to 40Gbps)
2x USB 3.2 Gen 2 Type-A (data speed up to 10Gbps)
1x HDMI 2.1 FRL
1x 3.5mm Combo Audio Jack
1x DC-in
SD Express 7.0 card reader |
"
"| Audio | Smart Amp Technology
Built-in speaker
Built-in array microphone |
"
| Voice control | N/A |
| Power | Rectangle Conn, 200W AC Adapter, Output: 20V DC, 10A, 200W, Input: 100~240V AC, 50/60Hz universal |
"| Required charging power | Min: 45W
Max: 100W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
"
| Battery | 90WHrs, 4S1P, 4-cell Li-ion |
| Replaceable Battery | No |
| Weight (with Battery) | 1.85 kg (4.08 lbs) |
| Weight (without Battery) | 1.80 kg (3.97 lbs) |
| Dimension (W x H x D) | 35.49 x 24.69 x 1.49 ~ 1.73 cm (13.97" x 9.72" x 0.59" ~ 0.68") |
"| Built-in Apps | ASUS Recovery
CapCut
MuseTree
StoryCube
MyASUS
ProArt Creator Hub
ScreenXpert
GlideX |
"
"| MyASUS feature | System diagnosis
Battery health charging
Fan Profile
Splendid
Function key lock
WiFi SmartConnect
TaskFirst
Live update
ASUS OLED Care
AI Noise Canceling |
"
| Content for GoPro free subscription | 6-Month GoPro Premium+ Subscription |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| Antivirus | N/A |
"| Security | IR webcam with Windows Hello support
Microsoft Pluton security processor
Trusted Platform Module (Firmware TPM) |
"
"| Adobe Creative Cloud Hard Bundle | 3-Month Membership of Adobe Creative Cloud All Apps, Individual.
The redemption duration from September 15, 2021 to August 31, 2026. |
"
"| Ecolabels & Compliances | Energy star 8.0
RoHS
REACH |
"
| Reparability Index (for France) | 9.5 |
| |
| Záruka | Celosvetová záruka na hardvér 2 roky, 1 rok záruka na batériový článok |
